河北悍象CD5T-24M電動葫蘆生產廠家，鋼絲繩電動葫蘆，額定起重500公斤～5噸，起升高度1米～100米，根據結構可分為普通電動葫蘆和非標電動葫蘆，標準起升速度8m/min，運行速度20m/min。安裝方式有固定式和運行式，單獨使用或安裝在直的、彎曲的工字鋼軌道上。還可作為行吊葫蘆配套各種單梁起重機、旋臂起重機、雙梁起重機、門式起重機、橋式起重機、龍門吊使用，應用廣泛。
Hebei han xiang cd5t-24m electric hoist manufacturer, wire rope electric hoist, rated lifting 500 kg ~ 5 tons, lifting height of 1 meter ~ 100 meters, according to the structure can be pided into ordinary electric hoist and non-standard electric hoist, the standard lifting speed of 8m/min, the speed of 20m/min. Installation methods are fixed and running, used alone or installed on a straight, curved i-steel track. Can also be used as a line hoist supporting a variety of single-beam crane, slewing crane, double beam crane, gantry crane, bridge crane, gantry crane, widely used.
CD1鋼絲繩電動葫蘆工作級別為M3，額定電壓380v，持電負載率25％，周期10分鐘，屬斷續運轉也稱反復短時工作制。單排單輪吊鉤起升速度8m／min，滑輪倍率1／2；雙排雙輪起升速度4m/min，滑輪倍率2／4。河北悍象CD5T-24M電動葫蘆可安裝無線遙控器使用。
The working level of CD1 wire rope electric hoist is M3, rated voltage is 380v, the electric load holding rate is 25%, the cycle is 10 minutes, it is intermittent operation also called repeated short-time working system. Lifting speed of single-row single-wheel hook is 8m/min, pulley ratio is 1/2; Double row and double wheel lifting speed 4m/min, pulley ratio 2/4. Hebei han xiang cd5t-24m electric hoist can be installed with wireless remote control.
CD5T-24M電動葫蘆安裝檢查標準(Cd5t-24m electric hoist installation inspection standard)
1、作業地點：在操作者步行范圍內無障礙物。2、運行軌道：由地面觀察軌道上不應有異常。3、按鈕裝置（手電門）：起升、下降、左右、運行動作應靈敏、準確；同時按動一組按鈕電動葫蘆不得動作。4、限位器：空載吊鉤上升至限位位置時，限位應準確穩定。5、起重吊鉤：吊鉤在圓周360°，與垂直180°，范圍內應轉動靈活，滑輪轉動時無卡阻和碰撞，吊鉤螺母防松裝置無異常，鉤口閉鎖裝置正常。6、制動器：起升、下降及運行的制動應靈敏。7、導繩器：動作正常，排繩順暢。
1. Location: there is no obstacle within the walking distance of the operator. 2. Operation track: there should be no abnormality on the track observed from the ground. 3, button device (flashlight door) : lifting, descending, left and right, operation action should be sensitive and accurate; At the same time press a group of buttons electric hoist shall not move. 4. Limit device: when the no-load hook rises to the limit position, the limit shall be accurate and stable. 5, lifting hook, hook in circular 360 ° and 180 ° vertically, the scope should be flexible rotation, pulley rotates without jam and collision, hook nut locking device without exception, hook lock mouth to normal. 6, brake: lift, fall and operation of the brake should be sensitive. 7. Rope guide: normal operation and smooth rope arrangement.
河北悍象CD5T-24M電動葫蘆生產廠家，電動葫蘆規格型號齊全，被廣泛應用于港口、電力、鋼鐵、造船、石油化工、礦山、鐵路、建筑、冶金化工、汽車制造、塑料機械、工業控制、公路、大件運輸、管道輔助、邊坡隧道、井道治理防護、海上救助、海洋工程、機場建設、橋梁、航空、航天、場館等重要行業以及基礎建設工程的機械設備。張經理：15703121115(加微信)、郝經理：15703121233(加微信)報價。
Hebei han xiang cd5t-24m electric hoist manufacturer，Electric hoist with complete specifications, widely used in ports, electricity, steel, shipbuilding, petrochemical, mining, railway, building, metallurgy, chemical industry, automobile manufacturing, plastics machinery, industrial control, highway, bulk transportation, pipeline auxiliary tunnel and shaft, slope protection for governance, salvage, Marine engineering, airport construction, Bridges, aviation, spaceflight, venues and other important industries and infrastructure engineering machinery and equipment. Manager zhang: 15703121115(plus WeChat), manager hao: 15703121233(plus WeChat).
